Usage Scenarios:Goods: building materials, machinery and equipment, timber, seedlings, etc. Distance: ≤200km Working conditions: national highways, provincial roads, urban roads are supplemented by common speed
Maximum horsepower:300
Drive type:6X4
Wheelbase:5850+1350
Motor:YCK08300-60
Gearbox:9JS119TA(Iron) (Flange Power Take-Off)
Specification
| Vehicle type information | Auman Planetary 300 horsepower 6×4 traditional mixer truck chassis | Manufacturer's guide price (yuan) | 269200.00 yuan |
| Model features | The equipment that realizes the lifting, slewing and lifting of goods through hydraulic lifting and telescopic systems is usually assembled on trucks. | use | Goods: building materials, machinery and equipment, timber, seedlings, etc. Distance: ≤200km Working conditions: mainly national highways and provincial roads, supplemented by urban roads Common speed: 60-80km/h |
| Model platform | planet | Market segments | Straight arm crane 10T/12T |
| Vehicle announcement model | / | High/flat top | Flattened |
| Drive form | 6×4 | wheelbase | 5850+1350 |
| Body size | 2200 | Front/rear overhang | 1320/3155 |
| Rated load | / | Vehicle weight | / |
| Total mass | 25000 | Top speed | 89 |
| Type of energy | tradition | brand | Yuchai |
| Engine model | YCK08300-60 | Number of cylinders | 6 cylinders |
| Maximum output power | 221 | Maximum horsepower | 300 |
| Emissions (emissions) | 7698 | Emission standards | Country VI. |
| Rated speed | 2200 | Maximum torque | 1180 |
| Maximum torque speed | 1200-1700 | cab | Row and a half cab |
| The main driver's seat form | Airbag seats | Gearbox (gearbox model) | 9JS119TA(Iron) (Flange Power Take-Off) |
| Transmission (number of gears) | 9 gears | Shift form | MT |
| Chassis brand | Auman | Chassis series | planet |
| Chassis model | BJ5251JSQY6DPS-01 | Rear axle description (rear axle form) | Single-minus rear axle |
| Rear axle model F | 435 | The permissible load on the rear axle | 10T |
| Rear axle ratio | 5.143 to 5.571 to 4.875 | Steering machine | Domestic 117 bore steering gear |
| Frame size | 305×80×(8+6+6) | Front axle description | Self-adjusting arm - ABS - drum brake - ordinary wheel |
| The permissible load on the front axle | 7.5T | Ratio | / |
| Suspension form | Leaf springs | Number of springs | 10/10/10 |
| saddle | / | Number of tires | 10+1 |
| Tire specifications | 11.00R20(Steel) | Fuel tank (volume/material)/Power battery (power/energy type/brand) | 350L |
| Vehicle announcement | / | Vehicle origin | / |
| Tops branding | / | Tank / box dimensions | / |
| Tank/box volume | / | Other optional devices | Multi-function steering wheel, 4.845, 5.571 speed ratio, electric adjustment, electric heating and defrosting exterior mirrors, 360 panoramic surround view, 7-inch color screen LCD instrument, blind spot detection BSD, optional package 1 (7-inch MP5 + reversing image + Bluetooth function + navigation + no steering wheel CAN control), optional package 2 (7-inch MP5 + Bluetooth function + navigation). |
